LP-CC-1-6/10 - Eaton Bussmann 1.6A 600VAC/300VDC Class CC Time-Delay Current Limiting Fuse Dual Element

LP-CC-1-6/10

LP-CC-1-6/10 is a Bussmann Eaton Class CC current-limiting time-delay fuse rated at 1.6 amps for industrial and specialized circuit protection.This fuse features a dual-element design with a rejection style, providing fast short circuit protection and time-delay performance. It has an interrupt rating of 200 kA at 600 VAC and 20 kA at 300 VDC, suitable for high capacity systems. The fuse is non-indicating with ferrule end connections and constructed with a melamine tube for durability. It complies with UL, CSA certifications, CE marking, and RoHS standards.

Key Specifications
• Amperage Rating: 1.6 A
• Voltage Rating: 600 VAC / 300 VDC
• Class: CC
• Number of Elements: Dual
• Interrupt Rating: 200 kA at 600 VAC, 20 kA at 300 VDC
• Fuse Indicator: Non-indicating
• Mounting Type: Holder (Rejection Style)
• Response Time: 12 seconds at 200% rated current
• Connection Type: Ferrule end x ferrule end
• Material: Melamine tube
• Certifications: UL Listed, CSA Certified, CE Marked, RoHS Compliant
• Series: Low-Peak LP-CC

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LP-CC-1-6/10
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : Low-Peak
• Type : LP-CC
• Voltage : 600
• Amperage : 1
• AIC rating : 200kA@600V
• Diameter : 0.41
• Class Rating : CC
• Barrels : 1

Product Data

• UPC : 051712180481
• GTIN : 00051712180481
• Country of Origin : Mexico
• Dimensions : 0.41 in x 1.5 in x 0.41 in (Length/Depth x Height x Width)
• Weight : 0.15
• Certification : CE/UL-248-4 Guide JDDZ/CSA Class 1422-02
