LP-CC-1-4/10 - Bussmann Eaton Class CC Time Delay Fuse 1.4A 600VAC 300VDC 200kA Interrupt

LP-CC-1-4/10

LP-CC-1-4/10 is a Bussmann Eaton Class CC time delay, dual-element current limiting fuse rated at 1.4 amperes for industrial circuit protection.This fuse features a rejection style design with a 200kA interrupting rating at 600 VAC and 300 VDC, providing fast short-circuit protection and time-delay performance to prevent nuisance openings. It has a compact cartridge body measuring approximately 13/32 inch diameter by 1-1/2 inch length and mounts in a fuse holder. The fuse complies with NEC Section 110.9 and is suitable for protecting small horsepower motor circuits and general branch circuit applications.

Key Specifications
• Amperage: 1.4 A
• Voltage Rating: 600 VAC / 300 VDC
• Interrupting Rating: 200 kA at 600 VAC, 20 kA at 300 VDC
• Class: CC
• Fuse Type: Time Delay, Dual Element
• Mounting Type: Fuse Holder
• Body Type: Cartridge
• Dimensions: 0.41 in diameter x 1.5 in length
• Rejection Style: Yes
• Standards: NEC Section 110.9 compliant

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LP-CC-1-4/10
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : Low-Peak
• Type : LP-CC
• Voltage : 600
• Amperage : 1
• AIC rating : 200kA@600V
• Diameter : 0.41
• Class Rating : CC
• Barrels : 1

Product Data

• UPC : 051712180467
• GTIN : 00051712180467
• Country of Origin : Mexico
• Dimensions : 0.41 in x 1.5 in x 0.41 in (Length/Depth x Height x Width)
• Weight : 0.15
• Certification : CE/UL-248-4 Guide JDDZ/CSA Class 1422-02
