Product Info
- Manufacturer:Littelfuse
- Sub-Category:Fuse Part And Accessory
Description
LKS-70
LKS-70 is a renewable fuse link designed for use with Littelfuse RLS series fuses, providing reliable overcurrent protection for general purpose circuits. This LKS-70 fuse link is rated for 70 amps and 600 volts AC, suitable for Class H applications where available fault current does not exceed 10,000 amps. It is a non-current limiting, renewable fuse link commonly used in older electrical systems.
- Amperage: 70 A
- Voltage Rating: 600 VAC
- Fuse Type: Renewable Fuse Link
- Series: LKS for RLS Series Fuses
- Interrupt Rating: 10 kA
- UL Class: H
- Mounting Type: Renewable Fuse Block
- Response: Fast Blow
- Approvals: UL Listed, CSA Certified
- Application: General Purpose Feeder and Branch Circuits
- Physical Size: Standard Class H
- Obsolete Status: Yes (Replaced by FLSR Series)
Specifications
- Part Number: LKS-70
- Manufacturer : Littelfuse
- Brand : Littelfuse
- Category : Fuse
- Item Subcategory : Fuse Part And Accessory
- Section : Fuse Link
- Family : LKS Series
- Type : LKS
- Voltage : 6
Product Data
- UPC : 051712140706
- Country of Origin : United States
- Dimensions : 6 in x 1 in x 1 in (Length/Depth x Height x Width)
- Weight : 0.198
- Certification : RoHS Compliant
