Product Info
- Manufacturer:Littelfuse
- Sub-Category:Fuse Part And Accessory
Description
LKS-300
LKS-300 is a Littelfuse Class H renewable fuse link rated at 300 amperes and 600 volts AC for general purpose feeder and branch circuit protection.LKS-300 fuse links are designed for use with Littelfuse RLS series renewable fuse holders, providing low-cost protection where short-circuit currents do not exceed 10,000 amperes. This fuse link features a time-delay characteristic suitable for overload and short circuit protection in older electrical systems. The product is obsolete and replaced by newer designs but remains available for legacy equipment maintenance.
- Key Specifications
- Amperage: 300 A
- Voltage Rating: 600 V AC
- Fuse Class: Class H
- Type: Renewable Fuse Link
- Mounting: Fuse Block / Clip / Holder (RLS series)
- Interrupting Rating: Up to 10 kA (typical for Class H)
- Trip Unit: Time-delay (slow-blow)
- Certifications: UL Listed, CSA
- Obsolete: Yes, replaced by FLSR series
Specifications
- Part Number: LKS-300
- Manufacturer : Littelfuse
- Brand : Littelfuse
- Category : Fuse
- Item Subcategory : Fuse Part And Accessory
- Section : Fuse Link
- Family : LKS Series
- Type : LKS
- Voltage : 6
Product Data
- UPC : 051712143004
- Country of Origin : United States
- Dimensions : 6 in x 0.5 in x 1.5 in (Length/Depth x Height x Width)
- Weight : 0.109
- Certification : RoHS Compliant
