Product Info
- Manufacturer:Square D
- Sub-Category:Molded Case
Description
LHL3635029DC
LHL3635029DC is a Square D 350 amp, 600 volt, 3 pole molded case circuit breaker from the LHL Series designed for high interrupting capacity applications.This thermal magnetic circuit breaker features long time and instantaneous trip functions, suitable for 3-phase systems with feed-thru capability. It supports both line and load side lug terminals and is rated for 20kA interrupting capacity at 500 VDC, making it ideal for demanding industrial and commercial power distribution environments.
- Manufacturer: Square D
- Amperage: 350 A
- Voltage: 600 V AC/DC
- Poles: 3
- Series/Frame: LHL
- Trip Unit: Thermal Magnetic with Long Time and Instantaneous Trip
- Interrupt Rating: 20kA at 500 VDC
- Mounting Type: Feed-Thru
- Line & Load Side Lug Terminals
Specifications
- Part Number: LHL3635029DC
- Manufacturer : Square D
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : LHL Series
- Type : LHL
- Voltage : 600
- Amperage : 350
- Phase : 3
- Poles : 3
- AIC rating : 20kA@500VDC
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : L Frame
- Protection : Thermal Magnetic
Product Data
- Dimensions : Depth 42.13 in (107 cm) Width 31.50 in (80 cm) Height 78.39 in (199.1 cm)
- Weight : 20
