Product Info
- Manufacturer:Square D
- Sub-Category:Molded Case
Description
LHL26250V
LHL26250V is a Square D 2-pole molded case circuit breaker rated for 250 amps and 600 volts, designed for reliable overload and short circuit protection.This circuit breaker features thermal magnetic trip units providing both thermal sensing for overload and magnetic protection for short circuits. It supports manual trip operation with a push-to-trip button and is suitable for various mounting and termination configurations. The breaker has a high interrupting rating, ensuring safe interruption of fault currents.
- Manufacturer: Square D
- Type: LHL Series Molded Case Circuit Breaker
- Amperage: 250A
- Voltage Rating: 600V AC
- Poles: 2
- Trip Unit: Thermal Magnetic
- Interrupt Rating: 25kA at 600VAC, 35kA at 480VAC
- Mounting: Flexible platform with unit mount and I-Line construction options
- Manual Trip: Push-to-Trip feature
Specifications
- Part Number: LHL26250V
- Manufacturer : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : LHL Series
- Type : LHL
- Voltage : 600
- Amperage : 250
- Phase : 1
- Poles : 2
- AIC rating : 35kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : L Frame
- Protection : Thermal Magnetic
Product Data
- Dimensions : Depth 5.84 in (148.34 mm) Width 6 in (152.40 mm) Height 11 in (279.40 mm)
- Weight : 18
