LHL26250 - Square D 250A 2-Pole 600VAC Molded Case Circuit Breaker

LHL26250

LHL26250 is a 250-ampere, 2-pole, 600VAC molded case circuit breaker designed for manual circuit control and automatic current interruption during overload or short circuit conditions.

This thermal-magnetic circuit breaker features independent thermal sensing for overload protection and magnetic sensing for short circuit protection in each pole. The unit offers a flexible platform suitable for various mounting and termination configurations, with push-to-trip capability that allows manual tripping without exposure to live parts. Available in both unit mount and I-Line construction options.

• Amperage: 250A
• Voltage: 600VAC / 250VDC
• Poles: 2
• Interrupt Rating: 65kA at 240VAC, 35kA at 480VAC, 25kA at 600VAC, 50kA at 125-250VDC
• Trip Unit: Thermal-Magnetic
• Terminal Connection: Lug
• Mounting: Panel Mount
• Series: LH
• Manual Trip: Push-to-Trip

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LHL26250
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : LHL Series
• Type : LHL
• Voltage : 600
• Amperage : 250
• Phase : 1
• Poles : 2
• AIC rating : 35kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : L Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 785901358626
• GTIN : 00785901358626
• Country of Origin : Mexico
• Dimensions : 11 in (279.4 mm) x 6 in (152.4 mm) x 5.84 in (148.34 mm) (Height x Width x Depth)
• Weight : 14.46
