Product Info
- Manufacturer:Square D
- Sub-Category:Molded Case
Description
LHF36400V
LHF36400V is a Square D 3-pole molded case circuit breaker designed for 400 amp, 600 volt applications in the LHF series.This circuit breaker features a thermal-magnetic trip unit providing long-time and instantaneous protection. It is designed for I-Line style plug-in mounting and offers a high interrupting capacity of 35kA at 480V. The breaker is UL 489, CSA C22.2, and IEC 60947-2 certified, ensuring compliance with industry safety standards.
- Amperage: 400A
- Voltage Rating: 600V
- Poles: 3
- Mounting Type: I-Line Plug-In
- Interrupt Rating: 35kA @ 480V
- Series/Frame: LHF
- Trip Unit: Thermal-Magnetic
- Certifications: UL 489, CSA C22.2, IEC 60947-2
Additional Information
This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.
Specifications
- Part Number: LHF36400V
- Manufacturer : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : LHF Series
- Type : LHF
- Voltage : 600
- Amperage : 400
- Phase : 3
- Poles : 3
- AIC rating : 35kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : L Frame
- Protection : Thermal Magnetic
Product Data
- Dimensions : Depth 4 in (101.60 mm) Width 6 in (152.40 mm) Height 12.5 in (317.50 mm)
- Weight : 20
