LHF36300V - Square D 300A 600V 3 Pole Bolt-On Thermal Magnetic Circuit Breaker 35kA@480V

LHF36300V

LHF36300V is a 3 pole, 300 amp, 600 volt thermal magnetic circuit breaker from Square D, designed for reliable protection in industrial and commercial power distribution systems. This breaker features a bolt-on mounting configuration and a high interrupting rating for demanding applications. The LHF36300V is a member of the LHF Series and is built with a robust L-frame construction. It provides thermal magnetic protection with an adjustable trip unit, ensuring precise circuit control and safety. The breaker is suitable for use in systems requiring a 35kA interrupting rating at 480 volts, making it ideal for high fault current environments.

• 300 Amp current rating
• 600 Volt AC maximum voltage rating
• 3 Pole configuration
• Bolt-On mounting type
• 35kA interrupting rating at 480V
• LHF Series, L-frame construction
• Thermal Magnetic adjustable trip unit
• UL Listed, CSA Certified
• Complies with IEC standards
• RoHS/REACH compliant
• Terminal wire size: 1 AWG to 600 KCMIL Aluminum
• Manual trip capability without exposure to live parts

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.

Specifications

• Part Number: LHF36300V
• Manufacturer : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : LHF Series
• Type : LHF
• Voltage : 600
• Amperage : 300
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : L Frame
• Protection : Thermal Magnetic

Product Data

• Dimensions : Depth 4 in (101.60 mm) Width 6 in (152.40 mm) Height 12.5 in (317.50 mm)
• Weight : 20
