Product Info
- Manufacturer:Square D
- Sub-Category:Molded Case
Description
LHF36250V
LHF36250V is a Square D 250 amp, 600 volt, 3 pole bolt-on molded case circuit breaker from the L Frame series.This circuit breaker features a thermal-magnetic trip unit with long-time and instantaneous protection functions. It is designed for unit mount installation with a bolt-on connection type. The breaker has a high interrupting capacity rated at 35kA at 480V, suitable for demanding power distribution applications.
- Key Specifications
- Amperage: 250 Amps
- Voltage Rating: 600 Volts
- Poles: 3
- Mounting Type: Bolt-On
- Interrupt Rating: 35kA at 480V
- Frame Size: L Frame
- Trip Unit: Thermal-Magnetic
- Connection: Bolt-On
- Part Number: LHF36250V
- Manufacturer : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : LHF Series
- Type : LHF
- Voltage : 600
- Amperage : 250
- Phase : 3
- Poles : 3
- AIC rating : 35kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : L Frame
- Protection : Thermal Magnetic
- Dimensions : Depth 4 in (101.60 mm) Width 6 in (152.40 mm) Height 12.5 in (317.50 mm)
- Weight : 20
Additional Information
This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.
