LH36350 - Square D 350A 600VAC 3-Pole I-Line Molded Case Circuit Breaker 35kA Interrupt Rating

LH36350

LH36350 is a Square D 350 Amp, 3-pole molded case circuit breaker designed for I-Line connection mounting systems.This thermal magnetic type breaker is rated for 600 VAC operation with a high interrupting capacity of 35,000 AIC at 480V and 25,000 AIC at 600V. It is suitable for power distribution applications in panelboards and switchboards, featuring UL and CSA certifications. The breaker supports phase A, B, and C and is built to the LH series/frame specifications.

• Amperage: 350A
• Voltage Rating: 600 VAC
• Poles: 3
• Mounting Type: I-Line Connection Mount
• Interrupt Rating: 35kA at 480V, 25kA at 600V
• Trip Unit: Thermal Magnetic
• Series/Frame: LH
• Certifications: UL, CSA
• Phase: A, B, C
• Dimensions: Approx. 6" W x 5.84" D x 11" H

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LH36350
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : I-Line
• Type : LH
• Voltage : 600
• Amperage : 350
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : I-Line, Lug
• Frame Size : H
• Protection : Thermal Magnetic

Product Data

• UPC : 785901339427
• GTIN : 00785901339427
• Country of Origin : Mexico
• Dimensions : 12.5 in (317.5 mm) x 6 in (152.4 mm) x 4 in (101.6 mm) (Height x Width x Depth)
• Weight : 18.25
• Standards : CSA, UL Listed
• Certification : CSA, UL Listed
