LH36175 - Square D 175 Amp 600V 3 Pole I-Line Style Molded Case Circuit Breaker Thermal Magnetic

LH36175

LH36175 is a Square D 175 Amp, 600 Volt, 3 Pole I-Line Style Molded Case Circuit Breaker with thermal magnetic trip unit technology.This circuit breaker features a plug-on mounting type designed for I-Line panelboards and switchboards. It has a high interrupting rating of up to 35 kAIC at 480V and 25 kAIC at 600V, suitable for power distribution applications. The breaker supports a frame type LH and is UL and CSA approved. It accommodates wire sizes from 1 AWG to 600 KCMIL copper or aluminum and provides reliable thermal magnetic tripping for overload and short circuit protection.

• Amperage: 175 A
• Voltage Rating: 600 VAC
• Poles: 3
• Mounting Type: I-Line Plug-On
• Interrupting Rating: 35 kAIC @ 480V, 25 kAIC @ 600V
• Frame Type: LH
• Trip Unit: Thermal Magnetic
• Certifications: UL, CSA
• Wire Size Capacity: 1 AWG to 600 KCMIL
• Dimensions: Approx. 6" W x 5.84" D x 11" H
• Phase: ABC

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LH36175
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : I-Line
• Type : LH
• Voltage : 600
• Amperage : 175
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Frame Size : L Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 785901710486
• GTIN : 00785901710486
• Dimensions : 12.5 in (317.5 mm) x 6 in (152.4 mm) x 4 in (101.6 mm) (Height x Width x Depth)
• Weight : 20
• Certification : UL, CSA
• Wire Size : AWG 1, 600 kcmil Aluminium/Copper)1, AWG 1, 250 kcmil Aluminium/Copper)2
