LGS3400FAG - Cutler Hammer Series G LG-Frame 3-Pole 400A Molded Case Circuit Breaker, Fixed Thermal Adjustable Magnetic Trip

LGS3400FAG

LGS3400FAG is a Cutler Hammer Series G LG-frame molded case circuit breaker featuring fixed thermal and adjustable magnetic trip for reliable protection in industrial and commercial applications. This three-pole 400A breaker is designed for use in 240V, 480V, and 600V systems with high interrupt ratings and HACR rating for HVAC compatibility. The breaker includes line and load terminals, metric mounting hardware, and is suitable for a wide range of electrical distribution panels. This Eaton Series G circuit breaker is UL Listed, CSA Certified, CE Marked, and IEC Rated, ensuring compliance with major safety standards. The LG-frame design provides robust performance and durability for demanding environments. The breaker is 80% rated for continuous load applications and operates at 50/60 Hz.

• Part Number: LGS3400FAG
• Manufacturer: Cutler Hammer (Eaton)
• Series: Series G
• Frame: LG
• Poles: 3
• Amperage Rating: 400A
• Max Voltage: 600V
• Interrupt Rating: 85 kAIC at 240V, 50 kAIC at 480V, 25 kAIC at 600V
• Mounting Type: Metric
• Frequency Rating: 50/60 Hz
• Rating: 80% rated
• Terminals: Line and load
• Trip Unit: Fixed thermal, adjustable magnetic
• Certifications: UL Listed, CSA Certified, CE Marked, IEC Rated
• HACR Rated: Yes

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LGS3400FAG
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series G
• Type : LGS
• Voltage : 600
• Amperage : 400
• Phase : 3
• Poles : 3
• AIC rating : 50kA@480V
• Connection : Feed-Thru
• Functions : Long Time and Instantaneous Trip Functions
• Protection : Thermal Magnetic

Product Data

• UPC : 782116142583
• GTIN : 00782116142583
• Country of Origin : United States
• Dimensions : 4.09 in x 5.48 in x 5.48 in (Length/Depth x Height x Width)
• Weight : 16
• Certification : CSA Certified,UL Listed,IEC Rated,CE Marked
