LGH3250FAG - Cutler Hammer 250A 600VAC 3-Pole LG Series Molded Case Circuit Breaker

LGH3250FAG

LGH3250FAG is a Cutler Hammer 3-pole molded case circuit breaker rated for 250 amps and 600 volts AC, designed for panel mounting.This LG Series breaker features a fixed thermal and adjustable magnetic trip unit, providing reliable thermal magnetic protection with a high interrupt rating of 65kA at 480VAC and 100kA at 240VAC. It supports line and load side lug terminals and complies with UL 489 standards. The breaker is part of Eaton's Series G LG-frame family and weighs approximately 16.2 lbs.

• Manufacturer: Cutler Hammer (Eaton)
• Part Number: LGH3250FAG
• Amperage: 250 A
• Voltage Rating: 600 VAC max
• Poles: 3
• Interrupt Rating: 100kA @ 240VAC, 65kA @ 480VAC, 35kA @ 600VAC
• Trip Unit: Fixed Thermal / Adjustable Magnetic
• Mounting Type: Panel Mount
• Series/Frame: LG Series, Series G
• Terminal Type: Line and Load Side Lug Terminals
• Certifications: UL 489
• Weight: Approx. 16.2 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LGH3250FAG
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series G
• Type : LGH
• Voltage : 600
• Amperage : 250
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : Long Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 782116142736
• GTIN : 00782116142736
• Country of Origin : United States
• Dimensions : 4.09 in x 5.48 in x 5.48 in (Length/Depth x Height x Width)
• Weight : 16
• Certification : IEC Rated,CSA Certified,UL Listed,CE Marked
