LGE3250FAG - Cutler Hammer 250A 600V 3-Pole LG Series Molded Case Circuit Breaker, Fixed Thermal-Adjustable Magnetic Trip, 35kAIC@480V, Feed-Thru, Line/Load Lugs, Metric Mounting

LGE3250FAG

LGE3250FAG is a Cutler Hammer (Eaton) Series G LG-frame molded case circuit breaker designed for robust power distribution applications.

This 3-pole, 250A breaker operates at up to 600VAC and features a fixed thermal-adjustable magnetic trip unit, feed-thru connection, and line/load side lug terminals with metric mounting hardware. It is engineered for reliable protection in three-phase systems, offering both long-time and instantaneous trip functions for enhanced safety and flexibility.

Key Specifications
• Amperage: 250A
• Voltage: 600VAC
• Poles: 3
• Mounting Type: Metric hardware, feed-thru
• Interrupt Rating: 65kAIC @ 240V, 35kAIC @ 415V/480V, 18kAIC @ 600V
• Series/Frame: LG (Series G)
• Trip Unit: Fixed thermal, adjustable magnetic
• Connection: Line/load side lug terminals
• Frequency: 50-60 Hz
• Rating: 80% continuous
• Certifications: Not specified in available data
• Non-interchangeable trip

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LGE3250FAG
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series G
• Type : LGE
• Voltage : 600
• Amperage : 250
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Feed-Thru
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 782116142378
• GTIN : 00782116142378
• Country of Origin : United States
• Dimensions : 4.09 in x 5.48 in x 5.48 in (Length/Depth x Height x Width)
• Weight : 16
• Certification : UL Listed,IEC Rated,CSA Certified,CE Marked
