Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
LGB2B080B
LGB2B080B is a Siemens 80 amp, 2 pole molded case circuit breaker designed for panelboard mounting with bolt-on connection.This Siemens LGB2B080B circuit breaker features a 600 volt rating, LGB frame type, and thermal magnetic trip unit. It has an interrupting rating of 100kA at 240V and is UL approved for reliable protection in commercial and industrial applications.
- Amperage: 80A
- Voltage: 600V AC
- Number of Poles: 2
- Mounting Type: Panelboard
- Connection Type: Bolt-On
- Interrupting Rating: 100kA @ 240V
- Frame Type: LGB
- Trip Unit: Thermal Magnetic
- Approvals: UL Listed
- Phase: Single
Specifications
- Part Number: LGB2B080B
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : VL Series
- Type : LGB
- Voltage : 600
- Amperage : 80
- Phase : 1
- Poles : 2
- AIC rating : 100kA@240V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Temp Rating : -13¡F - 158¡F (-25¡C - 70¡C)
- Protection : Thermal Magnetic
Product Data
- UPC : 887621220167
- GTIN : 00887621220167
- Country of Origin : Mexico
- Dimensions : 1.969 x 2.87 x 4.998
- Weight : 1.852
- Certification : UL, CSA, IEC, NOM
- Wire Size : 8 - 1/0 AWS (CU/AL)
