LESRK70 - Edison Fuses 70A 600V Class RK1 Dual-Element Time-Delay Fuse

LESRK70

LESRK70 is a 70 amp, 600 volt Class RK1 dual-element time-delay fuse from Edison Fuses designed for high inrush current motor protection.This fuse features current-limitation for maximum short-circuit protection, electrically isolated end caps, and is suitable for use with IEC and NEMA starters when properly sized. It has a 200kA interrupt rating and is UL and CSA certified, providing reliable and safe circuit protection.

• Amperage: 70A
• Voltage Rating: 600 VAC
• Fuse Type: Class RK1
• Fuse Response: Dual-element, time-delay
• Interrupt Rating: 200kA RMS Symmetrical
• Poles: 1
• Mounting Type: Standard fuse holder
• High inrush current motor protection
• Electrically isolated end caps
• UL 248-12 and CSA C22.2 certified
• Non-indicating

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LESRK70
• Manufacturer : Edison Fuses
• Brand : Edison Fuses
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Voltage : 600
• Amperage : 70
• AIC rating : 200kA@600V
• Diameter : 1.11
• Class Rating : RK1
• Barrels : 1

Product Data

• UPC : 78263454842
• GTIN : 00782634548423
• Country of Origin : Mexico
• Dimensions : 7.88 in x 1.11 in x 1.11 in (Length/Depth x Height x Width)
• Weight : 2.2
• Certification : CSA Certified,UL Listed,RoHS Compliant
