LESRK175 - Edison Fuses 175A 600V Class RK1 Time-Delay Fuse 1 Pole 200kA Interrupt Rating

LESRK175

LESRK175 is a 175 amp, 600 volt Class RK1 time-delay fuse from Edison Fuses designed for high inrush current motor protection.This fuse features dual-element, current-limiting technology providing maximum short-circuit protection with a 200kA interrupt rating. It has electrically isolated end caps and is suitable for use in motor circuits requiring time-delay characteristics to handle startup currents. The LESRK175 is UL and CSA certified, non-indicating, and designed for standard 1-pole mounting.

Key Specifications
• Amperage: 175 Amps
• Voltage Rating: 600 VAC
• Fuse Type: Class RK1
• Poles: 1
• Mounting Type: Standard fuse holder
• Interrupt Rating: 200,000 A RMS Symmetrical
• Fuse Response: Time-Delay (Dual Element)
• End Caps: Electrically Isolated
• Certifications: UL 248-12, CSA C22.2 No. 248.12
• High inrush current motor protection
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: LESRK175
• Manufacturer : Edison Fuses
• Brand : Edison Fuses
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : LESRK Series
• Type : LESRK
• Voltage : 600
• Amperage : 175
• AIC rating : 200kA@600V
• Diameter : 1.61
• Class Rating : RK1
• Barrels : 1



Product Data

• UPC : 782634548492
• GTIN : 00782635000000
• Dimensions : 9.63 in x 1.61 in x 1.61 in (Length/Depth x Height x Width)
• Weight : 1.1
