Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Trip Units & Programmers
Description
LES3600LSIG
LES3600LSIG is a solid-state electronic trip unit manufactured by Eaton (Series C family) designed for use in molded-case circuit breaker frames. This model supports a 600 A rating, three-pole configuration, and provides LSIG protection—Long-time, Short-time, Instantaneous and Ground-fault trip functions. This trip unit is intended for various Series C breaker frames (such as LD, HLD, LDC, CLD, CHLD, CLDC) and is rated for systems up to 600 V AC. It is suited for industrial and commercial branch-circuit and feeder protection applications.
- Part Number: LES3600LSIG
- Manufacturer: Eaton
- Series / Family: Series C – LSIG solid-state electronic trip unit
- Poles: 3-pole
- Amperage Rating: 600 A
- Trip Functions: Long-time (L) + Short-time (S) + Instantaneous (I) + Ground Fault (G)
- Maximum Voltage Rating: Up to 600 V AC
- Application: Interchangeable trip unit for Series C molded-case circuit breakers
Specifications
- Part Number: LES3600LSIG
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Trip Units & Programmers
- Family : Series C
- Type : LES
- Voltage : 600
- Amperage : 600
- Poles : 3
- Functions : LSIG - Long Time, Short Time, Instantaneous and Ground Fault Trip
- Frame Size : 600
- Amperage Maximum : 600
- Amperage Minimum : 600
- Protection : Solid State
Product Data
- UPC : 786679268407
- GTIN : 00786679268407
- Country of Origin : United States
- Dimensions : 9 in x 6 in x 5.5 in (Length/Depth x Height x Width)
- Weight : 4.5 lb
- Certification : UL Listed
