Product Info
- Manufacturer:Edison Fuses
Description
LENRK60
LENRK60 is a 60 amp, 250 volt Class RK1 dual element time-delay fuse from Edison Fuses designed for reliable feeder and branch circuit protection.This LENRK60 fuse features current-limiting dual elements with time-delay characteristics to handle temporary overloads without nuisance blowing. It has a 200kA interrupting rating at 250 VAC and is UL and CSA certified. The fuse is 0.81 inches in diameter and 3 inches long with a ferrule mounting style.
- Amperage: 60A
- Voltage Rating: 250 VAC
- Fuse Type: Class RK1
- Time-Delay Dual Element
- Interrupting Rating: 200kA Symmetrical
- Dimensions: 0.81" diameter x 3" length
- Mounting: Ferrule
- Certifications: UL, CSA C22.2
- Application: Feeder/branch circuit protection
- Manufacturer: Edison Fuses
Specifications
- Part Number: LENRK60
- Manufacturer : Edison Fuses
- Brand : Edison Fuses
Product Data
- UPC : 78263453841
- GTIN : 00782634538417
- Dimensions : 3 in x 0.81 in x 0.81 in (Length/Depth x Height x Width)
- Weight : 0.001
