LENRK40 - Edison Class RK1 Time-Delay Dual-Element Fuse 40A 250V

LENRK40

LENRK40 is a Class RK1 time-delay dual-element fuse rated for 40 amperes at 250 volts AC, designed for high in-rush current motor protection and branch circuit applications.

The LENRK40 features true dual-element spring-trigger construction that allows sizing at 125% of full load amperage, providing superior current limitation and fault protection. This plug-in ferrule-design fuse delivers up to 40% more current limitation and up to 350% more I2t limitation under fault conditions compared to standard fuses. UL and CSA C22.2 approved, the fuse is non-indicating and suitable for use in standard fuse holders.

• Amperage Rating: 40 A
• Voltage Rating: 250 VAC
• UL Class: RK1
• Fuse Type: Time-Delay Dual-Element
• Interrupting Rating: 200,000 RMS Symmetrical Amps
• DC Rating: 250 VDC
• Overall Length: 3 inches
• Maximum Diameter: 13/16 inch
• Mounting: Plug-In Ferrule Design
• Operating Temperature Range: -40 to 120 degrees Celsius
• Certifications: UL, CSA C22.2
• SCCR: 200 kA

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LENRK40
• Manufacturer : Edison Fuses
• Brand : Edison Fuses

Product Data

• UPC : 78263453838
• GTIN : 00782634538387
• Dimensions : 3 in x 0.81 in x 0.81 in (Length/Depth x Height x Width)
• Weight : 0.001
