LENRK150 - Edison Class RK1 Time-Delay Fuse 150A 250V

LENRK150

LENRK150 is a Class RK1 dual-element, time-delay fuse rated for 150 amperes at 250 volts AC, designed for maximum short-circuit protection and high in-rush current motor protection in industrial and commercial applications.

The LENRK150 features current-limiting technology that provides Type 2 protection for IEC and NEMA starters when properly sized. Its time-delay characteristic permits 130% FLA sizing for backup motor protection against single-phase damage. The fuse includes electrically isolated end caps and low watt loss power consumption for efficient operation. This plug-in fuse is UL and CSA listed, meeting UL 248-12 and CSA C22.2 No. 248.12 standards for Class RK1 fuses.

• Amperage Rating: 150A
• Voltage Rating: 250VAC
• Fuse Class: RK1
• Fuse Type: Dual-Element, Time-Delay
• Interrupt Rating: 200kA RMS Symmetrical
• Mounting: Plug-In (1 Barrel)
• Response Time: Time Delayed
• Certifications: UL Listed, CSA Listed
• Agency File Number: JDDZ.E4273
• Current Limiting: Yes
• Motor Protection: High in-rush current protection

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LENRK150
• Manufacturer : Edison Fuses
• Brand : Edison Fuses
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : LENRK
• Type : LENRK
• Voltage : 250
• Amperage : 150
• AIC rating : 200kA@250V
• Connection : Plug-In
• Diameter : 1.61
• Class Rating : RK1
• Barrels : 1

Product Data

• UPC : 782634538486
• GTIN : 00782634538486
• Dimensions : 7.13 in x 1.61 in x 1.61 in (Length/Depth x Height x Width)
• Weight : 0.001
