Product Info
- Manufacturer:Edison Fuses
Description
LENRK10
LENRK10 is a 10 amp, 250 volt Class RK1 time-delay plug-in fuse designed for feeder and branch circuit protection.This fuse features a dual element, current-limiting design providing enhanced protection with up to 40% more current limitation and 350% more Amps-Squared-Second (I2t) limitation under fault conditions. It has a 200,000 amp interrupt rating and is UL and CSA certified for safety and reliability. The fuse is 2 inches long with a 9/16 inch diameter ferrule style mounting.
- Amperage: 10 Amps
- Voltage Rating: 250 VAC
- Fuse Type: Class RK1
- Speed: Time-Delay (Dual Element)
- Interrupt Rating: 200,000 Amps
- Mounting Type: Plug-In (Ferrule)
- Length: 2 inches
- Diameter: 9/16 inch
- Certifications: UL, CSA
- Series: LENRK
Specifications
- Part Number: LENRK10
- Manufacturer : Edison Fuses
- Brand : Edison Fuses
Product Data
- UPC : 78263453830
- GTIN : 00782634538301
- Dimensions : 2 in x 0.56 in x 0.56 in (Length/Depth x Height x Width)
- Weight : 0.001
