LENRK1.25 - Edison Fuses 1.25A 250V Class RK1 Dual Element Time-Delay Fuse 200kA Interrupt Rating

LENRK1.25

LENRK1.25 is a 1.25 amp, 250 volt Class RK1 dual-element time-delay fuse from Edison Fuses designed for high in-rush current motor protection and general-purpose circuit protection.

This LENRK series fuse features true dual-element spring-trigger construction allowing sizing at 125% full load amperes for motor backup protection. It provides superior overload, cycling capabilities, and extremely current limiting characteristics for enhanced short circuit protection. The fuse is rated for 200,000 RMS symmetrical amps interrupting capacity and is UL listed as a Class RK1 fuse suitable for AC power distribution mains, feeders, branch circuits, and motor protection applications.

• Amperage: 1.25 A
• Voltage Rating: 250 VAC
• Fuse Class: RK1
• Fuse Type: Dual Element Time-Delay
• Interrupting Rating: 200,000 RMS Symmetrical Amps
• High in-rush current motor protection
• Current limiting for short circuit protection
• UL Listed and CSA Certified
• Single pole, plug-in mounting
• Standard fuse size for general purpose and motor branch circuits

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LENRK1.25
• Manufacturer : Edison Fuses
• Brand : Edison Fuses

Product Data

• UPC : 78263453804
• GTIN : 00782634538042
• Dimensions : 2 in x 0.56 in x 0.56 in (Length/Depth x Height x Width)
• Weight : 0.001
