LD62B500L - Siemens 500A 600V 2-Pole Molded Case Circuit Breaker LD Frame

LD62B500L

LD62B500L is a Siemens 2-pole molded case circuit breaker designed for reliable protection in industrial and commercial power distribution systems. This breaker features a 500A continuous current rating and is rated for 600V AC, making it suitable for a wide range of applications requiring robust circuit protection. The LD frame construction provides durability and high in-rush current capability, supporting demanding electrical loads. The breaker is equipped with a push-to-trip button for easy manual operation and includes one accessory pocket for added flexibility. The trip unit is interchangeable, allowing for field adjustments and upgrades as needed. This breaker is assembled for standard 40°C operation and offers a standard breaking capacity with a 25kA interrupt rating at 600V.Key Specifications

• Part Number: LD62B500L
• Manufacturer: Siemens
• Series/Frame: LD
• Amperage: 500A
• Voltage Rating: 600V AC
• Number of Poles: 2
• Interrupt Rating: 25kA at 600V
• Mounting Type: Standard
• Operating Temperature: 40°C
• Trip Unit: Interchangeable
• In-Rush Current Capability: 450%
• Push-to-Trip Button: Yes

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LD62B500L
• Manufacturer : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Sentron Series
• Type : LD
• Voltage : 600
• Amperage : 500
• Phase : 1
• Poles : 2
• AIC rating : 35kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : LD Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 783643010925
• GTIN : 00783643010925
• Country of Origin : Mexico
• Dimensions : 12.992 x 8.661 x 6.693 inch
• Weight : 17.527
