Product Info
- Manufacturer:Edison Fuses
- Sub-Category:Low Voltage Fuse
Description
LCL800
LCL800 is an Edison Fuses Class L time delay fuse rated for 800 amperes and 600 volts AC, designed for reliable current limiting protection.This fuse features a dual element design providing current limiting and time delay characteristics, suitable for high-performance electrical applications. It is a bolt-on type with a 200 kA interrupt rating, ensuring safe operation under fault conditions. The LCL800 is part of the Edison Class L series, known for robust construction and consistent performance.
- Amperage: 800 A
- Voltage Rating: 600 V AC
- Fuse Class: L
- Time Delay: Yes, minimum 5 seconds at 500% rated current
- Interrupt Rating: 200 kA
- Mounting Type: Bolt-on
- Poles: Single pole
- Series: Edison LCL
- Current Limiting: Yes
- Trip Unit: Dual element
- Certifications: Eaton/Edison standard
Specifications
- Part Number: LCL800
- Manufacturer : Edison Fuses
- Brand : Edison Fuses
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : LCL Series
- Type : LCL
- Voltage : 600
- Amperage : 800
- AIC rating : 200kA@600V
- Diameter : 2.5
- Class Rating : L
- Barrels : 1
Product Data
- UPC : 782634605089
- GTIN : 00782634605089
- Country of Origin : Mexico
- Dimensions : 8.63 in x 2.39 in x 2.39 in (Length/Depth x Height x Width)
- Weight : 3.75
- Certification : CSA Certified,UL Listed,RoHS Compliant
