Product Info
- Manufacturer:Edison Fuses
- Sub-Category:Low Voltage Fuse
Description
LCL2000
LCL2000 is a Class L time-delay fuse from the Edison Fuses LCL Series, rated for 600V and 2000A applications. This single-barrel fuse features a copper link design and is engineered for high fault current protection in industrial and commercial power distribution systems. The LCL2000 fuse is current-limiting and provides reliable protection with a minimum 5-second time delay at 500% rated current. It is designed for use in fuse blocks and switchgear requiring a 3.5-inch diameter fuse. The fuse meets UL and CSA C22.2 standards for safety and performance.
- Part Number: LCL2000
- Manufacturer: Edison Fuses
- Fuse Type: Class L
- Amperage Rating: 2000A
- Voltage Rating: 600V
- Interrupt Rating: 200kAIC
- Mounting Type: Single Barrel
- Diameter: 3.5 inches
- Response Time: Time Delay
- Series: LCL Series
- Material: Copper Link
- Certifications: UL, CSA C22.2
Specifications
- Part Number: LCL2000
- Manufacturer : Edison Fuses
- Brand : Edison Fuses
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : LCL Series
- Type : LCL
- Voltage : 600
- Amperage : 2000
- AIC rating : 200kA@600V
- Diameter : 3.5
- Class Rating : L
- Barrels : 1
Product Data
- UPC : 78263460520
- GTIN : 00782634605201
- Dimensions : 10.75 in x 3.53 in x 3.53 in (Length/Depth x Height x Width)
- Weight : 6
