LC2D40G7 - Schneider Electric 40A 3-Pole Reversing Contactor TeSys Deca 120V AC Coil 440V AC-3 Motor Control

LC2D40G7

LC2D40G7 is a Schneider Electric 3-pole reversing contactor designed for motor control applications with a 40 ampere rating and 120V AC coil voltage.

This TeSys Deca series contactor supports AC-3 utilization category for motor control up to 440V and is equipped with 3 normally open power poles (3NO) and 1 NO + 1 NC auxiliary contacts. It features screw clamp terminals, mechanical and electrical interlocks, and is suitable for rail or surface mounting. The contactor is designed for integration in control systems with low consumption AC and DC control circuits and operates reliably in temperatures from -4 to 70 degrees Celsius. It complies with IEC 60947 standards and is optimized for electro domestic and HVAC applications.

• Amperage: 40 A
• Voltage: 440 V AC (power), 120 V AC coil
• Poles: 3 poles (3NO)
• Series: TeSys Deca (LC2D series)
• Control Circuit Type: AC
• Mounting Type: Rail/Surface mount
• Terminal Type: Screw clamp
• Auxiliary Contacts: 1 NO + 1 NC
• Operating Temperature: -4 to 70 °C
• Utilization Category: AC-3
• Mechanical and Electrical Interlock included
• Standards: IEC 60947 compliant

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This includes a 120 VAC coil.

Specifications

• Part Number: LC2D40G7
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Motor Control
• Item Subcategory : Contactor
• Voltage : 600
• Amperage : 60
• Poles : 3
• Temp Rating : -13–158 °F (-25–70 °C)
• Aux Contacts : 3 NO
• Coil Voltage Maximum : 110
• Coil Voltage Minimum : 110

Product Data

• UPC : 38911045525
• GTIN : 03389110455250
• Country of Origin : Czechia
• Dimensions : Width 6.50 in (165 mm) x Height 5.20 in (132 mm) x Depth 5.59 in (142 mm)
• Weight : 7.101
• Temp Rating : -13–158 °F (-25–70 °C)
• Certification : UL, CSA, IEC, EN, GOST, CCC, GL, LROS, BV, DNV, RINA
