Product Info
- Manufacturer:Schnieder Electric
- Sub-Category:Contactor
Description
LC1K1610T7
LC1K1610T7 is a TeSys K series 3-pole contactor from Schneider Electric designed for motor control applications up to 16A at 440V AC-3 duty. This IEC-standard contactor provides reliable switching for industrial motor circuits with a maximum power circuit voltage rating of 690V AC and signaling circuit voltage of 690V AC up to 400Hz. The unit features three normally open (3NO) main contacts with one auxiliary normally open contact and operates on a 24V AC coil supply at 50/60Hz frequency. Key Specifications
- Part Number: LC1K1610T7
- Manufacturer: Schneider Electric
- Contactor Type: TeSys K Series
- Poles: 3P (3 Normally Open)
- Contact Rating: 16A
- Power Circuit Voltage: 690V AC Maximum
- AC-3 Duty Rating: 440V
- Coil Voltage: 24V AC
- Frequency: 50/60Hz
- Auxiliary Contacts: 1 NO
- Termination: Screw Terminal
Specifications
- Part Number: LC1K1610T7
- Manufacturer : Schnieder Electric
- Brand : Schneider Electric
- Category : Motor Control
- Item Subcategory : Contactor
- Voltage : 690
- Amperage : 20
- Poles : 3
- Coil Voltage Maximum : 480
- Coil Voltage Minimum : 480
Product Data
- GTIN : 03389118319110
- Dimensions : Depth 2.24 in (57 mm) Width 1.77 in (45 mm) Height 2.28 in (58 mm)
- Weight : 0.75
