LC1K0601F7 - Schneider Electric TeSys K 3-Pole Motor Contactor 6A 110V AC Coil Surface Mount

LC1K0601F7

LC1K0601F7 is a Schneider Electric TeSys K 3-pole motor contactor designed for AC motor control applications with a 6 amp rating and 110V AC coil.This compact contactor features 3 normally open (3NO) power poles rated for 6A at 600 VAC, suitable for motor loads up to 2.2 kW at 400V. It includes a 110V 50/60 Hz AC coil, one normally closed (1NC) auxiliary contact, and screw clamp terminals. The device is surface mountable with an IP2X enclosure rating and supports operating temperatures from -25 to 50°C. It is part of the TeSys K line, known for small size and reliable motor control.

• Amperage: 6 A AC-3
• Voltage Rating: Up to 690 V AC
• Poles: 3 (3NO)
• Coil Voltage: 110 V AC, 50/60 Hz
• Mounting Type: Surface mount
• Contact Configuration: 3 normally open power poles + 1 normally closed auxiliary contact
• Terminal Type: Screw clamp
• Interrupt Rating: 20 A at 60°C power circuit
• Series/Frame: TeSys K
• Operating Temperature: -25 to 50°C
• Enclosure Type: IP2X
• Certifications: Compliant with IEC standards

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This TeSys K Miniature Contactor includes a 110 VAC coil.

Specifications

• Part Number: LC1K0601F7
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Motor Control
• Item Subcategory : Contactor
• Voltage : 600
• Amperage : 15
• Poles : 3
• Aux Contacts : 3 NO
• Coil Voltage Maximum : 110
• Coil Voltage Minimum : 110
• Frequency : AC 50/60 Hz

Product Data

• UPC : 3389110429374
• GTIN : 03389110429374
• Country of Origin : Indonesia
• Dimensions : 2.3 in (58 mm) x 1.8 in (45 mm) x 2.2 in (57 mm) (Height x Width x Depth)
• Weight : 0.395
• Certification : CB Scheme CCC UL CSA EAC CE UKCA
