LC1D80G7 - Schneider Electric TeSys D 3-Pole 80A 120V AC Coil Motor Contactor 60HP 480V

LC1D80-G7

LC1D80G7 is a Schneider Electric TeSys D series 3-pole motor contactor designed for reliable motor control applications.This IEC-rated contactor features a 120V AC coil operating at 50/60 Hz, supports up to 80A continuous current, and is suitable for motors up to 60 HP at 480V. It includes 3 normally open power poles and 1 NO + 1 NC auxiliary contact for control signaling. The compact design allows easy installation and maintenance, with multiple mounting options. It meets IEC 60947 standards and provides high durability and performance in demanding environments.

• Manufacturer: Schneider Electric
• Series: TeSys D
• Poles: 3 (3 NO power contacts)
• Rated Current: 80 A
• Control Voltage: 120 V AC, 50/60 Hz coil
• Motor Power Rating: 60 HP at 480 V AC
• Auxiliary Contacts: 1 NO + 1 NC
• Standards: IEC 60947 compliant
• Interrupt Rating: Up to 100 kA SCCR
• Mounting: Multiple flexible mounting options

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get(more...)

Specifications

• Part Number: LC1D80-G7
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Motor Control
• Item Subcategory : Contactor
• Family : TeSys D
• Type : LC1D
• Voltage : 600
• Amperage : 80
• Phase : 3
• Poles : 3
• Horse Power : 7.5 hp at 120 V AC 50/60 Hz for 1 phase motors-15 hp at 230/240 V AC 50/60 Hz for 1 phase motors-30 hp at 200/208 V AC 50/60 Hz for 3 phases motors-30 hp at 230/240 V AC 50/60 Hz for 3 phases motors-60 hp at 460/480 V AC 50/60 Hz for 3 phases motors-60 hp at 575/600 V AC 50/60 Hz for 3 phases motors
• Coil Voltage Maximum : 120
• Coil Voltage Minimum : 120

Product Data

• UPC : 038911044086
• GTIN : 00389110440860
• Weight : 7
• Certification : BV, CCC, CSA, CSA C22.2 No 14, DNV, EN 60947-4-1, EN 60947-5-1, GL, GOST, IEC 60947-4-1, IEC 60947-5-1, LROS, RINA, UL 508, UL Listed
