Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Contactor
Description
LC1D65AQ7C
LC1D65AQ7C is a Schneider Electric TeSys Deca 3-pole AC contactor rated for 65 amperes with a 440V coil voltage.This contactor features three normally open (3 NO) poles designed for AC-3 utilization category applications. It supports a voltage rating up to 440V and a current rating of 65A, suitable for motor control and power distribution. The device includes EverLink BTR screw connectors for power circuit wiring, allowing cable sizes from 1 to 35 mm_ with an external diameter of 16.5 mm. It operates with a coil frequency of 50-60 Hz and provides mechanical endurance of 3600 cycles per hour at 60 ¡C. The contactor has a fast opening time of 4 to 19 ms and closing time of 12 to 26 ms.
- Key Specifications
- Manufacturer: Schneider Electric
- Part Number: LC1D65AQ7C
- Current Rating: 65 Amperes
- Voltage Rating: Up to 440 Volts AC
- Number of Poles: 3 (3 Normally Open)
- Coil Voltage: 440V AC, 50/60 Hz
- Mounting Type: Panel Mount (standard for TeSys Deca series)
- Power Circuit Connection: EverLink BTR screw connectors
- Cable Size Range: 1 to 35 mm_
- Mechanical Endurance: 3600 (more...)
Specifications
- Part Number: LC1D65AQ7C
- Manufacturer : Schneider Electric
- Brand : Schneider Electric
- Category : Motor Control
- Item Subcategory : Contactor
- Family : TeSys D
- Type : LC1D
- Voltage : 600
- Amperage : 65
- Phase : 3
- Poles : 3
- Coil Voltage Maximum : 380
- Coil Voltage Minimum : 380
Product Data
- Weight : 2.108
- Certification : CE, UKCA, CCC
