Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Contactor
Description
LC1D65ACC7C
LC1D65ACC7C is a 3-pole IEC contactor from Schneider Electric's TeSys Deca series designed for motor control applications. This nonreversing contactor delivers reliable performance in industrial and HVAC environments with modern design features including improved fire resistance and dustproof auxiliaries. The unit features screw terminal connections rated for flexible cables up to 35 mm2 and operates across multiple utilization categories including AC-3 and AC-1 for versatile motor control. Key Specifications
- Amperage Rating: 65 A
- Poles: 3 Pole (3 NO)
- Control Circuit Voltage: 36V AC 50/60 Hz
- Power Circuit Voltage: Up to 440V AC
- Utilization Categories: AC-3, AC-1
- Contact Configuration: 3 Normally Open
- Terminal Type: Screw Clamp
- Operating Rate: 3600 cycles per hour at 60 degrees C
- Mechanical Life: 6 million cycles
- Insulation Resistance: Greater than 10 megohms
- Non-overlap Time: 1.5 ms on energization and de-energization
- IEC 60335-1 Compliant
Specifications
- Part Number: LC1D65ACC7C
- Manufacturer : Schneider Electric
- Brand : Schneider Electric
- Category : Motor Control
- Item Subcategory : Contactor
- Family : TeSys D
- Type : LC1D
- Voltage : 600
- Amperage : 65
- Phase : 3
- Poles : 3
- Coil Voltage Maximum : 36
- Coil Voltage Minimum : 36
Product Data
- Weight : 2.072
- Certification : CE, UKCA, CCC
