LC1D4011D7 - Schneider Electric 40A 3-Pole Motor Contactor 690V AC TeSys D Series

LC1D4011D7

This contactor belongs to the TeSys D series and supports motor control utilization categories AC-1, AC-3, and AC-4. It features 3 normally open (NO) power poles, suitable for controlling motors up to 30 HP at 460/480 V AC. The device operates with a 240 V AC control circuit voltage and is built to IEC 60947 standards, ensuring high performance and durability. It includes auxiliary contacts configured as 1 NO + 1 NC and supports screw connection terminals for power circuits. The contactor is rated for an operating temperature up to 60 ¡C and can handle a mechanical endurance of 6 million cycles.

Key Specifications
• Amperage: 40 A at <= 440 V AC (AC-3)
• Voltage: Up to 690 V AC, 25-400 Hz power circuit
• Poles: 3 poles, 3 normally open (NO)
• Control Circuit Voltage: 240 V AC, 50/60 Hz
• Motor Power Rating: Up to 30 HP at 460/480 V AC
• Auxiliary Contacts: 1 NO + 1 NC
• Mounting Type: Screw connection terminals
• Standards: (more...)


  Specifications

  • Part Number: LC1D4011D7
  • Manufacturer : Schneider Electric
  • Brand : Schneider Electric
  • Category : Motor Control
  • Item Subcategory : Contactor
  • Family : TeSys D
  • Type : LC1D
  • Voltage : 600
  • Amperage : 40
  • Phase : 3
  • Poles : 3
  • Coil Voltage Maximum : 24
  • Coil Voltage Minimum : 24



  Product Data

  • Weight : 5.19
  • Certification : BV, CCC, CSA, CSA C22.2 No 14, DNV, EN 60947-4-1, EN 60947-5-1, GL, GOST, IEC 60947-4-1, IEC 60947-5-1, LROS, RINA, UL 508, UL Listed
