LC1D4011B7 - Schneider Electric 40A 3-Pole Motor Contactor AC-3 440V Coil

LC1D4011B7

LC1D4011B7 is a Schneider Electric 3-pole motor contactor rated for 40 amps and designed for reliable motor control applications.This contactor supports AC-3 utilization category with a rated operational current of 40A at voltages up to 440V AC. It is suitable for controlling three-phase motors up to 10 HP at 230V and 30 HP at 460V. The device includes 1 normally open (NO) and 1 normally closed (NC) auxiliary contact, mechanically linked for enhanced operational flexibility. It is compatible with standard 35mm DIN rail or panel mounting and offers long mechanical and electrical durability.

Key Specifications
• Rated operational current: 40A AC-3 at ² 440V AC
• Voltage rating: Up to 440V AC
• Poles: 3-pole
• Horsepower rating: 10 HP at 230V, 30 HP at 460V (3-phase)
• Auxiliary contacts: 1 NO + 1 NC
• Mounting type: DIN rail or panel mount
• Durability: 10 million mechanical cycles, 1.5 million electrical cycles (AC-3)
• Terminal type: Screw clamp with IP20 finger-safe protection
At Essential Parts, we offer fast shipping, lowest price, (more...)


Specifications

• Part Number: LC1D4011B7
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Motor Control
• Item Subcategory : Contactor
• Family : TeSys D
• Type : LC1D
• Voltage : 600
• Amperage : 40
• Phase : 3
• Poles : 3
• Coil Voltage Maximum : 24
• Coil Voltage Minimum : 24



Product Data

• Weight : 5.19
• Certification : BV, CCC, CSA, CSA C22.2 No 14, DNV, EN 60947-4-1, EN 60947-5-1, GL, GOST, IEC 60947-4-1, IEC 60947-5-1, LROS, RINA, UL 508, UL Listed
