LC1D38T7 - Schneider Electric TeSys D 3-Pole 38A 440V AC Contactor with 480V AC Coil

LC1D38T7

LC1D38T7 is a Schneider Electric TeSys D series 3-pole contactor designed for motor control applications with a 38 ampere current rating and 440V AC operational voltage.This contactor features 3 normally open poles (3NO) suitable for AC-3 and AC-3e utilization categories, supporting motor loads up to 18.5 kW at 400V and rated for voltages up to 690V AC. It includes a 480V AC coil rated for 50/60 Hz operation and screw clamp terminals for secure wiring. The device offers mechanical durability up to 15 million operating cycles and fast switching times with 4 to 19 ms opening and 12 to 22 ms closing times. It is optimized for reliable motor control with a frame designed for easy installation and maintenance.

Key Specifications
• Current rating: 38 Amps
• Operational voltage: 440V AC (up to 690V AC max)
• Poles: 3 poles, 3 normally open (3NO)
• Coil voltage: 480V AC, 50/60 Hz
• Utilization category: AC-3 / AC-3e
• Power rating: 18.5 kW at 400V
• Terminal type: Screw clamp terminals (2 x 1 to 2.5 mm_ cable)
• Mechanical durability: 15 million cycles
• Opening time: 4 to 19 ms
• Clo(more...)


  Specifications

  • Part Number: LC1D38T7
  • Manufacturer : Schneider Electric
  • Brand : Schneider Electric
  • Category : Motor Control
  • Item Subcategory : Contactor
  • Family : TeSys D
  • Type : LC1D
  • Voltage : 600
  • Amperage : 55
  • Phase : 3
  • Poles : 3
  • Temp Rating : -13‰ÛÒ158 å¡F (-25‰ÛÒ70 å¡C)
  • Coil Voltage Maximum : 480
  • Coil Voltage Minimum : 480



  Product Data

  • Country of Origin : France
  • Weight : 0.816
  • Temp Rating : -13‰ÛÒ158 å¡F (-25‰ÛÒ70 å¡C)
  • Certification : BV, CCC, CSA, CSA C22.2 No 14, DNV, EN 60947-4-1, EN 60947-5-1, GL, GOST, IEC 60947-4-1, IEC 60947-5-1, LROS, RINA, UL 508, UL Listed
