Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Contactor
Description
LC1D258F7C
LC1D258F7C is a nonreversing, 4-pole IEC contactor from Schneider Electric's TeSys Deca series designed for motor control and resistive load switching applications. This contactor features 2 NO (normally open) and 2 NC (normally closed) contacts with a 40A rated current capacity for AC-1 duty up to 690V. The unit is equipped with a 110VAC 50/60Hz control coil and utilizes screw clamp terminals for secure wiring connections. Built to meet industrial and HVAC application requirements, the LC1D258F7C incorporates improved fire resistance with IEC60335-1 compliance and dustproof auxiliary contacts for enhanced reliability in demanding environments. The contactor features a modern design with multi-standard screws for easier installation and operation across different mounting configurations.
- Manufacturer: Schneider Electric
- Series: TeSys Deca
- Configuration: 4-Pole (2NO+2NC)
- Rated Current: 40A
- Duty Type: AC-1 Resistive Load
- Maximum Voltage: 690V
- Control Coil Voltage: 110VAC
- Control Frequency: 50/60Hz
- Terminal Type: Screw Clamp
- Compliance: IEC60335-1
- (more...)
Specifications
- Part Number: LC1D258F7C
- Manufacturer : Schneider Electric
- Brand : Schneider Electric
- Category : Motor Control
- Item Subcategory : Contactor
- Family : TeSys D
- Type : LC1D
- Voltage : 600
- Amperage : 25
- Phase : 3
- Poles : 4
- Coil Voltage Maximum : 120
- Coil Voltage Minimum : 110
Product Data
- Weight : 0.985
- Certification : CE, UKCA, CCC
