LC1D09M7C - Schneider Electric TeSys Deca 9A 3-Pole 440V 220VAC Contactor

LC1D09M7C

LC1D09M7C is a TeSys Deca nonreversing IEC contactor designed for motor control applications, rated 9A at 440V AC with a 220V AC 50/60Hz coil. This 3-pole contactor features 3 normally open (NO) main contacts and 1 NO + 1 NC auxiliary contacts, making it suitable for direct on-line motor starting in industrial and HVAC applications. The contactor is rated for up to 5 HP at 480VAC and delivers reliable performance across multiple voltage ranges including 380-440V AC-3 and 500-690V AC-3 ratings. Built with improved fire resistance per IEC 60335-1 compliance, dustproof auxiliaries, and multi-standard screws for easier installation. The unit features screw clamp terminals and offers mechanical durability of 15 million cycles with an operating rate of 3600 cycles per hour at temperatures up to 60 degrees Celsius.

• Amperage: 9A
• Poles: 3-pole (3NO)
• Main Voltage: 440V AC maximum
• Coil Voltage: 220V AC 50/60Hz
• Auxiliary Contacts: 1 NO + 1 NC
• Motor Power: 5 HP at 480VAC, 4 kW at 415-440V AC-3
• Duty: AC-3/3e motor control
• Mechanical Durability: 15 million cycles
• Terminal Type: Screw clamp

Specifications

• Part Number: LC1D09M7C
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Motor Control
• Item Subcategory : Contactor
• Family : TeSys D
• Type : LC1D
• Voltage : 600
• Amperage : 9
• Phase : 3
• Poles : 3
• Coil Voltage Maximum : 220
• Coil Voltage Minimum : 220



Product Data

• Weight : 0.795
• Certification : CE, UKCA, CCC
