LBY55 Crouse-Hinds Condulet LBY Explosionproof Pulling Elbow, 1-1/2 In

LBY55

LBY55 Crouse-Hinds Condulet LBY Explosionproof Pulling Elbow, 1-1/2 In

The LBY55 is a Crouse-Hinds Condulet LBY series 90 degree pulling elbow built for 1-1/2 in rigid or IMC conduit runs in hazardous and classified locations. Manufactured from Feraloy iron alloy with an electrogalvanized finish, the LBY55 is rated for Class I, Divisions 1 and 2, Groups C and D, Class II, Division 1, Groups E, F, and G, Class II, Division 2, Groups F and G, and Class III locations, and is listed to UL1203 and CSA C22.2 No. 30.

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Taper threaded hubs with an integral bushing accept standard rigid threaded conduit, and a screw-on cover with an angled opening allows conductors to be pulled straight through either hub without straining insulation.

Common Applications

• 90 degree direction changes in conduit runs where space is limited
• Pull outlet for conductor access during installation
• Access point for conductor maintenance and future system changes

Key Features

• Screw-on cover: Simplifies installation and removal for conductor access
• Angled cover opening: Permits conductors to be pulled straight through either hub
• Taper threaded hubs: Integral bushing accepts standard rigid threaded conduit
• Compact body volume: Maximizes bend volume within a compact overall size

Specifications

• Catalog Number: LBY55
• Manufacturer: Eaton Crouse-Hinds series
• Product Type: Condulet LBY elbow, 90 degree
• Trade Size: 1-1/2 in
• Conduit Type: Rigid/IMC
• Material: Feraloy iron alloy
• Finish: Electrogalvanized
• Hazardous Location Rating: Class I, Divisions 1 and 2, Groups C, D; Class II, Division 1, Groups E, F, G; Class II, Division 2, Groups F, G; Class III
• Standards: UL1203, CSA C22.2 No. 30

Product Identification

• Product Weight: 3.2 lb
• Product Dimensions: 3.38 in L/D x 4.5 in H x 3.38 in W
• UPC: 782274277097
• GTIN: 00782274277097

FAQ

• What is the LBY55? The LBY55 is a Crouse-Hinds Condulet LBY series 90 degree pulling elbow for 1-1/2 in rigid or IMC conduit in hazardous locations.
• What trade size is the LBY55? The LBY55 accepts 1-1/2 in conduit.
• What material is the LBY55 made from? The LBY55 is manufactured from Feraloy iron alloy and finished electrogalvanized.
• What hazardous location classes is the LBY55 rated for? Class I, Divisions 1 and 2, Groups C and D; Class II, Division 1, Groups E, F, and G; Class II, Division 2, Groups F and G; and Class III.
• What standards is the LBY55 listed to?


  Specifications

  • Part Number: LBY55
  • Manufacturer : Eaton
  • Brand : Crouse-Hinds
  • Category : Conduit & Fittings
  • Item Subcategory : Rigid-IMC
  • Section : Explosionproof Conduit Unions, Elbows and Tees
  • Family : LBY
  • Material : Feraloy iron alloy
  • NEC hazardous rating : Class I, Division 1 Class I, Division 2 Class II, Division 1 Class II, Division 2 Class III
  • Trade size : 1-1/2"



  Product Data

  • UPC : 782274277097
  • GTIN : 00782274277097
  • Dimensions : 3.38 in x 4.5 in x 3.38 in (Length/Depth x Height x Width)
  • Weight : 3.2 lb
