Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Overload Relay
Description
LB1LD03M53
LB1LD03M53 is a Square D thermal magnetic overload relay designed for motor control applications with adjustable thermal settings from 23 to 32 amps and 3 poles.This overload relay features a thermal magnetic trip unit with a tripping class 20, magnetic protection range of 190 to 380 amps, and is rated for 600 volts AC. It is part of the Integral series and provides reliable motor protection by preventing overload and short circuit conditions. The device is suitable for use with motor controllers and circuit breakers, ensuring enhanced motor safety and operational efficiency.
- Manufacturer: Square D
- Part Number: LB1LD03M53
- Type: Thermal Magnetic Overload Relay
- Poles: 3
- Thermal Current Range: 23-32 Amps
- Magnetic Trip Range: 190-380 Amps
- Voltage Rating: 600V AC
- Trip Class: 20
- Series: Integral
- Mounting Type: Panel Mount
- Interrupt Rating: Suitable for motor protection
- Certifications: UL, IEC compliant
Specifications
- Part Number: LB1LD03M53
- Manufacturer : Schneider Electric
- Brand : Schneider Electric
- Category : Motor Control
- Item Subcategory : Overload Relay
- Voltage : 600
- Amperage : 2000
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : LIGA - Long-Time, Instantaneous and Ground Fault Alarm
- Protection : Solid State
Product Data
- Weight : 2.251
