LA36250 - Square D 250A 600V 3-Pole Molded Case Circuit Breaker, Thermal Magnetic, I-Line Plug-On Frame LA

LA36250

LA36250 is a Square D 250 Amp, 600 Volt, 3-pole molded case circuit breaker designed for reliable power distribution protection.This circuit breaker features a thermal magnetic trip unit, I-Line plug-on mounting, and a frame type LA. It is rated for 22kA interrupting capacity at 600VAC and 250VDC, suitable for panelboard and switchboard applications. The breaker complies with UL 489 and CSA certifications, ensuring safety and performance standards.

• Manufacturer: Square D
• Part Number: LA36250
• Frame Type: LA
• Amperage: 250A
• Voltage Rating: 600VAC, 250VDC
• Poles: 3
• Mounting Type: I-Line Plug-On
• Interrupt Rating: 22kA at 600VAC
• Trip Unit: Thermal Magnetic
• Certifications: UL 489, CSA
• Application: Power Distribution, Panelboard, Switchboard

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LA36250
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : I-Line
• Type : LA
• Voltage : 600
• Amperage : 250
• Phase : 3
• Poles : 3
• AIC rating : 30kA@480V
• Connection : Plug In Panelboard
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : Lug
• Frame Size : 400A/LA
• MCM Size : Min. Wire Size 1/0 AWG Max. Wire Size 250 MCM, 600 MCM
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : ABC

Product Data

• UPC : 785901426202
• GTIN : 00785901426202
• Country of Origin : Mexico
• Dimensions : 11 in (279.4 mm) x 6 in (152.4 mm) x 5.84 in (148.34 mm) (Height x Width x Depth)
• Weight : 18.25
• Panel Type : I Line Panelboards
• Standards : CSA, UL Listed
• Certification : CSA, UL Listed
