Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Motor Control Part And Accessory
Description
LA2DT4
LA2DT4 is a Telemecanique time delay auxiliary contact block with 10 amp rating and 1 normally open (NO) plus 1 normally closed (NC) contact configuration.This auxiliary contact block features screw clamp terminals for secure wiring and is designed for use with Telemecanique TeSys D contactors. It provides a time delay function with an adjustable range of 10 to 180 seconds, suitable for motor control applications. The unit is rated for 10 amps and up to 690V, meeting IEC 947 and other international standards. It has been discontinued and replaced by the LADT4 model.
- Amperage: 10A
- Voltage rating: Up to 690V
- Contact configuration: 1 NO + 1 NC
- Mounting type: Auxiliary contact block for TeSys D contactors
- Terminal type: Screw clamp terminals
- Time delay range: 10 to 180 seconds
- Standards: IEC 947, VDE 0660, BS 4794
- Discontinued: Yes, replaced by LADT4
- Manufacturer: Telemecanique (Schneider Electric)
Specifications
- Part Number: LA2DT4
- Manufacturer : Schneider Electric
- Brand : Telemecanique
- Category : Motor Control
- Item Subcategory : Motor Control Part And Accessory
- Section : Timers
- Family : TeSys D
- Type : LA2D
- Voltage : 600
- Amperage : 400
- Phase : 3
- Poles : 3
Product Data
- Weight : 5
