LA1KN40 - Square D TeSys K Auxiliary Contact Block 4NO 10A 600VAC Front Mount Screw Clamp

LA1KN40

LA1KN40 is a Square D TeSys K auxiliary contact block designed for motor control applications with a 4 normally open (4NO) contact configuration.

This auxiliary contact block features a clip-on front mounting style with screw clamp terminals, suitable for use with TeSys K contactors and control relays. It supports a control circuit voltage up to 600VAC and a current rating of 10 amps. The LA1KN40 is UL and CSA certified, meeting IEC 60947-5-1 standards for industrial control equipment.

• Manufacturer: Square D
• Series: TeSys K
• Contact Configuration: 4 Normally Open (4NO)
• Mounting Type: Clip-on Front Mount
• Terminal Type: Screw Clamp
• Rated Current: 10 Amps
• Rated Voltage: 600 VAC
• Certifications: UL, CSA, IEC 60947-5-1
• Application: Motor Control Auxiliary Contact Block

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LA1KN40
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Motor Control
• Item Subcategory : Contactor And Motor Starter Auxiliary
• Voltage : 690 AC
• Amperage : 2000
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : LSIGA - Long-Time, Short-Time, Instantaneous and Ground Fault Alarm
• Configuration : Instantaneous
• Aux Contacts : 4 NO
• Protection : Solid State

Product Data

• UPC : 3389110500073
• GTIN : 03389110500073
• Country of Origin : Indonesia
• Dimensions : 1.2 in (30 mm) x 1.5 in (38 mm) x 1.4 in (35 mm) (Height x Width x Depth)
• Weight : 0.088
• Certification : EN/IEC 60947-5-1, UL 60947-5-1, CSA C22.2 No 60947-5-1, GB/T 14048.5, JIS C8201-5-1, CB, CCC, CE, UKCA
