Product Info
- Manufacturer:Littelfuse
- Sub-Category:Fuse Block
Description
L60030M-2C
L60030M-2C is a 30 amp, 600 volt, 2 pole molded-case fuse block from Littelfuse designed for reliable circuit protection.This fuse block features a bolt-in mounting method and is constructed with high-strength, high-temperature thermoplastic material to minimize damage during handling and heat exposure. It includes side barriers for isolation and high conductivity one-piece copper alloy fuse clips to reduce resistance and heat rise. The block is gangable for multi-pole configurations and compatible with DIN rail mounting using optional adapters. It is UL Class CC rated and suitable for general purpose fuse applications.
- Current Rating: 30 Amps
- Voltage Rating: 600 VAC/DC
- Number of Poles: 2
- Mounting Type: Bolt-In (Chassis Mount)
- Fuse Type: Midget
- UL Class: CC
- Material: High-strength thermoplastic
- Fuse Clips: One-piece copper alloy
- Isolation: Side barriers
- Gangable for multi-pole assembly
- DIN rail mountable with adapter
- Approvals: UL, CSA
Specifications
- Part Number: L60030M-2C
- Manufacturer : Littelfuse
- Brand : Littelfuse
- Category : Fuse
- Item Subcategory : Fuse Block
- Family : L600M
- Type : L600M
- Voltage : 600
- Amperage : 30
- Mounting : Box Lug
Product Data
- UPC : 079458009590
- GTIN : 00079458009590
- Country of Origin : China
- Weight : 1
- Certification : UL Listed CSA
