Product Info
- Manufacturer:Telemecanique
- Sub-Category:Limit Switch
Description
L100WS2M1
L100WS2M1 is a severe duty limit switch from Telemecanique designed for industrial applications with 600 V rating and 10 A current.This L100 series limit switch features spring return operator, DPDT-DB contact configuration (1 NC + 1 NO per direction), cast aluminium body, screw-clamp terminals, and 1/2" NPT cable entry. It offers IP67 protection, high shock and vibration resistance, and precise repeat accuracy of +/- 0.03% for reliable operation in harsh environments.Key Specifications
- Part Number: L100WS2M1
- Manufacturer: Telemecanique
- Voltage Rating: 600 V
- Current Rating: 10 A
- Number of Poles: 2
- Contact Configuration: DPDT-DB
- Connection: Screw-clamp terminals
- Cable Entry: 1/2" NPT
- Body Material: Cast aluminium
Specifications
- Part Number: L100WS2M1
- Manufacturer : Telemecanique
- Brand : Telemecanique
- Category : Sensors
- Item Subcategory : Limit Switch
- Family : L100
- Voltage : 600 V
- Amperage : 10 A
- Poles : 2
- Connection : Screw-clamp terminals
- Enclosure : IP67
Product Data
- UPC : 785901161639
- GTIN : 00785901000000
- Weight : 2
