KTS-S-200 - Cooper Bussmann 200A 600V Class RK1 Fast-Acting Current Limiting Fuse

KTS-S-200

KTS-S-200 is a Cooper Bussmann Class RK1 fast-acting current limiting fuse rated for 200 amps and 600 volts AC.This fuse features a single-element, fast-acting design with a high interrupting rating of 200 kAIC at 600 VAC. It uses a melamine glass tube construction with blade end connections and is designed for rejection style mounting. The KTS-S-200 is ideal for protecting circuits with no heavy surge currents, such as transformers, solenoids, and welders, and provides excellent short-circuit current limitation.

Key Specifications
• Amperage Rating: 200 A
• Voltage Rating: 600 V AC
• Interrupting Rating: 200 kAIC at 600 VAC
• Fuse Class: RK1
• Fuse Type: Fast-Acting, Current Limiting
• Mounting Type: Rejection Style
• Material: Melamine Glass Tube
• Connection: Blade End x Blade End
• Number of Elements: 1
• Fuse Indicator: Non-Indicating
• Certifications: CE Marked
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: KTS-S-200
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage
• Family : LIMITRON
• Type : KTS
• Voltage : 600
• Amperage : 200
• AIC rating : 200kA@600V
• Connection : Knife Blade
• Diameter : 1.5
• Class Rating : RK1
• Barrels : 1



Product Data

• Weight : 5.19
