Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
KTS-R-1
KTS-R-1 is an Eaton Class RK1 fast-acting, current-limiting fuse rated for 1 ampere and 600 volts AC.
This single-element fuse provides fast-acting protection with a high interrupting rating of 200 kA at 600 VAC. It features a rejection style design compatible with non-rejection fuse holders and offers reliable short-circuit current limitation for panelboard applications. The fuse is UL Listed to Standard 248-12 and CE marked, ensuring compliance with industry safety standards.
- Key Specifications
- Amperage: 1 A
- Voltage Rating: 600 VAC
- Interrupt Rating: 200 kA RMS Symmetrical
- Class: RK1
- Fuse Type: Fast-Acting, Current-Limiting
- Number of Elements: 1
- Mounting Type: Rejection Style
- Certifications: UL Listed, CE Marked
- Part Number: KTS-R-1
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : LIMITRON
- Type : KTS-R
- Voltage : 600
- Amperage : 1
- AIC rating : 200kA@600V
- Diameter : 0.81
- Class Rating : RK1
- Barrels : 1
- UPC : 051712417006
- GTIN : 00051712417006
- Dimensions : 5 in x 0.81 in x 0.81 in (Length/Depth x Height x Width)
- Weight : 0.15
