KTK-R-25 - Eaton Bussmann 25A 600VAC Class CC Fast Acting Fuse, Limitron, 200kA Interrupt Rating

KTK-R-25

KTK-R-25 is a fast-acting Class CC fuse from Eaton Bussmann designed for branch circuit protection.This 25 amp, 600 VAC fuse features a Limitron® fast-acting characteristic with a melamine tube construction and ferrule terminal. It has a compact size of 13/32 inch diameter by 1-1/2 inch length and offers a high interrupting rating of 200,000 amperes symmetrical at 600 VAC. The fuse is UL 248-4, CSA, and CE certified, providing reliable current-limiting protection with Class CC rejection style.

Key Specifications
• Amperage: 25 A
• Voltage Rating: 600 VAC
• Fuse Type: Fast Acting, Limitron®
• Interrupting Rating: 200,000 A Symmetrical
• Fuse Series: KTK-R Class CC
• Size: 13/32 inch diameter x 1-1/2 inch length
• Mounting Type: Ferrule Terminal
• Material: Melamine Tube
• Certifications: UL 248-4, CSA, CE
• Rejection Style: Class CC

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: KTK-R-25
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : LIMITRON
• Type : KTK-R
• Voltage : 600
• Amperage : 25
• AIC rating : 200kA@600V
• Diameter : 0.41
• Class Rating : CC
• Barrels : 1

Product Data

• UPC : 051712420730
• GTIN : 00051712420730
• Country of Origin : Mexico
• Dimensions : 1.5 in x 0.41 in x 0.41 in (Length/Depth x Height x Width)
• Weight : 0.18
• Certification : CE/UL-248-4 Guide JDDZ/CSA Class 1422-02
