KTK-R-1/10 - Bussmann Eaton Class CC Fast Acting Fuse 0.1A 600V 1 Pole LIMITRON

KTK-R-1/10

KTK-R-1/10 is a Bussmann Eaton Class CC fast-acting fuse rated for 0.1 amps and 600 volts AC, designed for branch circuit protection.This KTK-R series fuse features a LIMITRON fast-acting design with a melamine tube and nickel-plated bronze end caps, providing reliable current limiting and rejection style mounting for specialized circuits and industrial control.

Key Specifications
• Amperage: 0.1 Amps
• Voltage Rating: 600 Volts AC
• Poles: 1
• Fuse Type: Fast Acting, Current Limiting
• Interrupting Rating: 200,000 AIC RMS @ 600VAC
• Mounting Type: Rejection Style
• Physical Size: 0.41" x 1.5"
• Series: LIMITRON KTK-R
• Construction: Melamine Tube with Nickel Plated Bronze End Caps
• Certifications: UL Listed (Std. 248-14, Guide #JDYX, File #E19180), CSA Certified (C22.2 NO. 248.14)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: KTK-R-1/10
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : LIMITRON
• Type : KTK-R
• Voltage : 600
• Amperage : 1
• AIC rating : 200kA@600V
• Diameter : 0.41
• Class Rating : CC
• Barrels : 1

Product Data

• UPC : 051712420518
• GTIN : 00051712420518
• Country of Origin : Mexico
• Dimensions : 1.5 in x 0.41 in x 0.41 in (Length/Depth x Height x Width)
• Weight : 0.18
• Certification : CE/UL-248-4 Guide JDDZ/CSA Class 1422-02
