KRP-C-650SP - Bussmann 650A 600V Class L Time Delay Fuse 300kA Interrupt Rating

KRP-C-650SP

KRP-C-650SP is a 650 Amp, 600 Volt AC Class L time delay fuse designed for high capacity electrical protection.This Bussmann fuse features a minimum 4-second time delay at 500% rated current, current limiting capability, and a 300,000 AIC interrupting rating at 600VAC. It is UL listed and CSA certified for special purpose use, suitable for overload and short circuit protection in industrial applications.

• Amperage: 650 Amps
• Voltage Rating: 600VAC / 300VDC
• Class: L Fuse
• Time Delay: Minimum 4 seconds at 500% rated current
• Interrupting Rating: 300,000 AIC RMS @ 600VAC, 100,000 AIC @ 300VDC
• Current Limiting
• Physical Size: 2.5" x 8.63"
• Mounting Type: Cartridge Blade Fuse
• Certifications: UL Listed (Guide JFHR, File E56412), CSA Certified (Class 1422-02, File 53787)
• Series: Bussmann KRP-C

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: KRP-C-650SP
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : Low-Peak
• Type : KRP-C
• Voltage : 600
• Amperage : 650
• AIC rating : 300kA@600V
• Diameter : 2.4
• Class Rating : L
• Barrels : 1

Product Data

• UPC : 051712605076
• GTIN : 00051712605076
• Country of Origin : Mexico
• Dimensions : 8.63 in x 2.53 in x 2.53 in (Length/Depth x Height x Width)
• Weight : 3.8
• Certification : CSA, UL
